1. Features
• The light distribution and its mounting types are especially designed for the platform.
• It adopts American CREE LED as light source, can save 60% or more on energy than the metal halide
lamp.
• The housing is designed to dissipate heat, which increase the efficiency and the lifespan of the LED, so
that to ensure the 100,000 hours led lifespan.
• Supplied with the world top ranking Taiwan Meanwell LED driver, ensure the lamp of high perfor
mance, more efficient.
• The anti corrosion, abrasion proof, power coated cover which is dust proof, water proof , make the
lamp an excellent option for all kinds of high stress environment.
• 18~43VAC or 18~55VDC is optional for 25W and 40W as customer’s requirement.
2. Application
• Ideal to be used in the oilfield, chemical industry, steel industry, power, port, Petroleum etc.
• Harsh environment, moist area.
• Gas explosive environment : Group IIA, IIB, IIC
• Zone 1, Zone2; Zone 21, Zone 22
• Temperature class: T1 to T6
3. Technical Specifications
Input Voltage 90~264VAC / 127~370VDC
Frequency 50Hz / 60Hz
Anti Corrosion Grade WF2
Insulation Grade I
Space Height Ratio 2
Thread G3/4’’
Leading-in cable
diameter 8mm — 14mm
Dimension 240x160mm
Net Weight 4Kg
